7m USB 3.2 Type C to C Cable, 10Gbps, 100W PD, Anthra Line

Part No: 36909
  • £52.99
75 In Stock Now   |
Loading...

Product Summary

  • Fast data transfer speeds up to 10Gbps, suitable for large file transfers, regular backups, and reliable high-resolution media streaming.
  • Delivers up to 100W of power via USB Power Delivery (20V 5A) to rapidly charge laptops, tablets, and mobile phones, keeping devices powered throughout demanding workdays.
  • Supports video at up to 4K 60Hz via DisplayPort Alternate Mode, enabling high-resolution video output for today´s laptops, workstations, and AV systems.
  • Featuring triple-shielded cable and gold-plated contacts for superior performance, signal integrity, and durability in mission-critical environments.
  • A 10-year warranty makes this cable ideal for long-term deployments in professional and commercial installations.
The Anthra Line USB 3.2 Gen 2x1 Type C, 100W PD cables from Lindy are purpose-built for high-performance AV and IT applications. Part of Lindy´s professional-grade Cable Lines range, they combine premium materials with advanced engineering for maximum reliability.

An integrated E-Mark chip enables safer 100W (20V 5A) fast charging with USB Power Delivery, allowing for the voltage and current to be automatically adjusted to the needs of connected devices such as mobile phones, tablets and laptops to prevent overvoltage and overcurrent.

USB 3.2 Gen 2x1 offers impressive 10Gbps transfer speeds, making it ideal for moving large video files, connecting external SSDs or to use with VR headsets.

DisplayPort Alternate Mode enables crisp 4K video output at 60Hz, making them perfect for connecting to high-resolution displays and AV equipment. The robust triple-shielded design with tinned copper conductors and gold-plated connectors ensures excellent signal quality and strong resistance to EMI/RFI in challenging environments.

With reversible USB Type C connectors and full bi-directional communication, these cables guarantee simple, reliable connections every time.

Disclaimer: The cable´s extended length may affect overall performance. Actual power delivery and data transfer speeds depend on the capabilities of the connected devices. Please note that this cable is not compatible with the Logitech RallyBar 2 or Logitech Meetup webcam.

Connectors

  • Connector A: USB 3.2 Type C Male
  • Connector B: USB 3.2 Type C Male
  • Housing Material: PVC
  • Shielding in head shell: Nickel-plated iron
  • Connector Plating: Nickel
  • Pin Construction: Copper
  • Pin Plating: Gold
  • Dimensions (approx.) WxDxH: 12.7x31x7mm (0.5x1.22x0.28in)

Cable Construction

  • Jacket Diameter: 5.1mm (0.2in)
  • Jacket Material: PVC
  • Conductor Material: Tinned Copper
  • Conductor Gauge Power: 25AWG
  • Conductor Gauge Data: 28/32/34AWG
  • Shielding: AL Mylar, tinned copper

Specifications

  • Length: 7m (22.97ft)
  • Colour: Black
  • Type: Round
  • Standard: USB 3.2 Gen 2x1
  • Supported Bandwidth: 10Gbps
  • Power Delivery: PD 3.0 with up to 100W (20V 5A)
  • E-Mark: Yes
  • Maximum Resolution: 4K 4096x2160@60Hz
  • Supported Protocols: USB 3.2, USB 2.0, DisplayPort 1.4
  • Nominal Attenuation:
    • 100MHz, -3dB
    • 2500MHz, -7.5dB
    • 5000MHz, -10.5dB
    • 10000MHz, -15dB
    • 12500MHz, -18dB
    • 15000MHz, -21.2dB
  • Minimum Bend Radius: 51mm (2.01in)
  • Operating Temperature: -20°C - 60°C (-4°F - 140°F)
  • Storage Temperature: -20°C - 80°C (-4°F - 176°F)

Miscellaneous

  • Packaging Type: Polybag
  • Warranty (Years): 10
  • Product Compliance: RoHS, REACH, California Proposition 65 & UL (raw cable only)

Purchasing Information

  • No.: 36909
  • EAN: 4002888369091

This product is also available in other lengths

  • 36904 - 3m (9.84ft)
  • 36908 - 5m (16.4ft)
  • 36909 - 7m (22.97ft)
