IPower Switch Classic 16

Part No: 32658
  • £785.76
30 In Stock Now   |
Loading...

Product Summary

  • Remote management switch for up to 16 computers or other devices
  • Control via simple to use browser interface or software
  • Built-in web server, supports real time monitoring for the current consumption of the power strip
  • Provides audio alarm when the power consumption exceeds the value for overload warning
  • 2 year warranty

SECTION 1 - HERO HEADLINE

Remote Power Management for Larger IT and AV Installations



The Lindy IPower Switch Classic 16 provides convenient remote switching, rebooting and power monitoring for up to 16 connected devices, making it ideal for server rooms, network environments and professional AV installations where reliable power control is essential.

SECTION 2 - FEATURE CALLOUT

Control and Monitor Up to 16 Devices Remotely

Designed for larger deployments, the IPower Switch Classic 16 allows system administrators and installers to remotely power connected equipment on or off, perform reboots and monitor overall current consumption through a simple browser interface or software. This helps reduce downtime, simplifies maintenance and gives better control of critical infrastructure across IT, network and AV environments.

SECTION 3 - AT A GLANCE

At a Glance

Remote control for up to 16 devices
Ideal for servers, routers, hubs and AV equipment.

Browser and software control
Simple remote access across existing networks.

Real-time power monitoring
Track current consumption and review usage charts.

Overload warning with audio alarm
Helps protect connected equipment and installations.

SECTION 4 - KEY BENEFITS

Key Benefits

Convenient remote power control
Switch outlets on or off and reboot connected devices remotely, reducing the need for physical access to racks, comms rooms or equipment cabinets.

Supports larger multi-device installations
With 14 IEC C13 outlets and 2 IEC C19 outlets, the unit is well suited to managing a broad mix of IT, network and AV equipment from a single power management point.

Real-time monitoring and usage reporting
The built-in web server supports monitoring of current consumption, while power consumption charts for daily, monthly or custom periods provide useful operational insight.

Visible status and overload warning
Each outlet features status indication, while the display shows the current IP address directly and an audio alarm warns when power consumption exceeds the configured overload threshold.

Built for professional rack environments
The robust metal housing and rack mount design make the switch suitable for structured installations where dependable power control and monitoring are required.

Flexible power input for higher load requirements
The IEC C20 power input supports operation from a 16A circuit, providing greater total switched power capacity where the appropriate mains cable is used.



SECTION 5 - TYPICAL APPLICATIONS

Typical Applications

The IPower Switch Classic 16 is ideal for server rooms, network cabinets, control rooms, digital signage infrastructures and professional AV systems where multiple devices need to be restarted or managed remotely. It is especially useful in environments where fast recovery, simplified support and visibility of power usage can improve uptime and reduce manual intervention.



SECTION 6 - TECHNICAL SUMMARY

Technical Summary

The Lindy IPower Switch Classic 16 supports input voltages from 110-240V and provides a maximum switched power of up to 2400W per port and 3120W total, depending on the circuit and power cable used. It features one IEC C20 input, 14 IEC C13 outputs, 2 IEC C19 outputs and an RJ45 10Mbps Ethernet port for network connection. The built-in display shows the unit’s IP address, while monitoring functions provide real-time current measurement and power usage charts. Please note that SSL is not supported, and this product is supplied without a mains power cable. Rack mounting brackets and screws are included, and the unit is backed by a 2-year warranty.

Specifications

  • Input Voltage: 110-240V
  • Switched Power (per port): max. 2400W (240V 10A)
  • Switched Power (total): max. 3120W (240V 13A or 240V 16A using optional "Commando" to IEC C19 Power Cable)
  • Nominal Input Frequency: 47-63 Hz Full Range
  • Current Range: 0A~20A (True RMS)
  • Current Amperage: 0A~20A: +/- 2% (+/- 0.1A)
  • Current Meters: 3 digits
  • LED Indicators: 1x yellow LED, 1x red LED

Connectors

  • Input: IEC C20
  • Output: 14x IEC C13, 2x IEC C19
  • Network Connection : RJ45 10Mbps Ethernet Port

Physical Properties

  • Dimensions (approx.) WxDxH:  1255x55x45mm (49.412x2.17x1.77in)
  • Housing Material: Metal
  • Net Weight: 3kg (6.61lb)
  • Operating Temperature: -5–45°C (23°F–113°F)
  • Storage Temperature: -25–65°C (-13°F–149°F)
  • Humidity: 0-95% (non-condensing)
  • Colour: Black

Miscellaneous

  • Packaging Type: Carton
  • Packaging Dimensions: 1355x210x106mm (53.35x8.27x4.17in)
  • Gross Weight: 4.2kg (9.26lb)
  • Warranty (Years): 2
  • Certification: CE, UKCA, FCC, RoHS, REACH, EMC, LVD

Package Contents

  • IPower Switch Classic 16
  • Rack mount brackets and screws
  • Lindy Quick Installation Guide

Purchasing information

  • No.: 32658
  • EAN: 4002888326582
