DST-Mini Plus Laptop Docking Station | USB-C | 1x 4K HDMI®, 1x VGA | Pass-Through Charging

The DST-Mini Plus with VGA is a compact, multifunctional solution for hybrid workers. Housed in a robust aluminium with a high-quality braided USB-C cable, this dock has been designed for durability during travel. With support for HDMI® and VGA, it is ideal for those who have an older legacy monitor they wish to plug their device into.

Extended Displays

This docking station can support a 4k extended display at 30Hz or 1080p Full HD 60Hz via its HDMI® port. It does this through a single USB-C connection using DisplayPort Alternate Mode. Alternatively, you can access crisp 1080p Full HD via the legacy VGA connection. If both video outputs are connected, 1080p Full HD is possible with the displays showing mirroring content

Added Connectivity

Providing three SuperSpeed USB Type A ports (5Gbps), Card Readers (SD & microSD), USB-C PD, Gigabit Ethernet, VGA and HDMI, the DST-Mini Plus unlocks a world of connectivity for your device. With a single USB-C connection, you can connect USB accessories such as keyboard and mice as well as expand your storage and take advantage of a lightening quick wired Ethernet connection.

Pass-through Charging

Thanks to the USB-C Power Delivery, by connecting a USB-C charger to the docking station you can expect up to 100W charging to any connected laptop (depending on the USB-C charger and how much power the dock is using). Simply connect one USB-C cable and be confident that all your connected device will be fully charged and ready to go.

Plug-and-Play

This docking station does not require any driver installation. This allows for seamless large-scale implementation and a hassle-free experience.

Specifications

• Interface: USB Type C to 1x VGA / 1x HDMI® / 1x RJ45 / 3x USB 3.0 Type A / 1x microSD / 1x SD
• Supported Bandwidth: HDMI® 1.4 with 10.2Gbps, USB 3.1 Gen 1 / USB 3.0 (5 Gbps), Gigabit LAN (10/100/1000Mbps)
• Maximum Input Resolution: 3840x2160@30Hz
• Maximum Output Resolution:
• 3840x2160@30Hz (HDMI®), 1920x1080@60Hz (VGA)
• Simultaneous connection with the same video content:
1920x1080@60Hz each (VGA / HDMI®)
• Chipset: RTL8153B, EP9632G, GL3510
• Compatibility: USB Type C or Thunderbolt 3/4 equipped computers with DisplayPort Alternate Mode support. Windows, macOS, Linux, Android, ChromeOS
• Power Delivery: PD 3.0 up to 100W (20V 5A)
• HDCP Support: HDCP2.2
• Supported Audio: -
• Separate Audio Ports: -
• Special Features: DisplayPort Alternate Mode, supports MAC Address pass through (this feature is dependent upon the compatibility of the hardware used in each set up),  supports Legacy PXE (eHCI and xHCI) & UEFI PXE

Connectors

• Inputs: 1 x USB Type C (Male)
• Outputs: 1x USB Type C (Female), 1x VGA (Female), 1x HDMI® (Female), 1x RJ45 (Female), 3x USB Type A (Female), 1x SD slot, 1x microSD slot
• Power: -

Physical Properties

• Dimensions WxDxH: 180x17x49mm (7.09x0.67x1.93in)
• (Fixed cable length): 150mm (5.91in)
• Housing Material: Aluminium
• Net Weight: 0.09kg (0.2lb)
• Operating Temperature: 0° - 45°C (32°F - 113°F)
• Storage Temperature: -20°C - 60°C (-4°F - 140°F)
• Humidity: 20 – 80% RH (non-condensing)
• Power Requirements: 15W
• Colour: Grey

Miscellaneous

• Packaging Type: Polybag
• Packaging Dimensions: 174x194mm (6.85x7.64in)
• Gross Weight: 0.1kg (0.22lb)
• Warranty (Years): 2
• Certified: CE, UKCA, FCC, REACH & RoHS, CP65

Package contents

• USB 3.2 Type C Laptop Mini Docking Station
• Lindy Manual
