DST-Mini XT Laptop Docking Station | USB-C | 1x 4K HDMI®/DP, 2x 1080p HDMI® | 100W PD

The DST-Mini XT is Lindy’s feature-packed mini docking station. Housed in robust aluminium, this compact dock has been designed for those who need greater additional connectivity, in a portable form factor.

Extended Displays

The DST-Mini XT can support a single extended display at 4K@30Hz through the HDMI® or DisplayPort connections. Dual display setups are also possible with crisp Full HD 1080p. This makes this dock the perfect solution for any creative, data analyst or intense spreadsheet worker.

Added Connectivity

This docking station can unlock a world of connectivity for your device. Delivering DisplayPort, HDMI®, Gigabit Ethernet, SD Card Slot, USB-C, SuperSpeed USB Type A ports (5Gbps) and a combined 3.5mm headphone jack. To deliver as much added functionality as possible, the right USB Type A port has both SuperSpeed data transfer and Battery Charging 1.2, meaning you can charge connected mobile devices.

Pass-through Charging

Thanks to the USB-C PD 3.0, by connecting a USB-C charger to the DST-Mini XT you can expect up to 100W charging of the connected laptop. With Battery Charging 1.2, one of USB Type A port delivers 5V and up to 1.5A for faster charging. Simply connect one USB-C cable and be confident that your laptop and connected devices will be fully charged and ready to go.

Plug-and-Play

This docking station does not require any driver installation. This allows for seamless large-scale implementation and a hassle-free experience.

Specifications

• Interface: USB Type C to 1x HDMI® / 1x DP / 1x RJ45 / 2x USB Type A / 1x USB Type C / 1x SD / 1x Audio (combo)
• Supported Bandwidth: HDMI® 1.4 with 10.2Gbps, DP 1.2 with 21.6Gbps, USB 3.2 / 3.1 Gen 1 / USB 3.0 (5 Gbps), Gigabit LAN (10/100/1000 Mbps)
• Maximum Input Resolution: 3840x2160@30Hz
• Maximum Output Resolution: 3840x2160@30Hz (HDMI®), 3840x2160@30Hz (DP), simultaneous connection: 1920x1080
• Chipset: VL102-Q4, VMM3332, RTL8153B, VL817, FE1.1S, GL823K, HS-100B, VL163, MP28167
• Compatibility: USB Type C/Thunderbolt equipped computers with DisplayPort Alternate Mode support. Windows, macOS, Linux, Android, ChromeOS
• Power Delivery: PD 3.0 up to 100W (20V 5A)
• HDCP Support: HDCP 1.4
• Supported Audio: Supports 48/44.1kHz Audio sampling rate
• Separate Audio Ports: 1x Audio combo port 3.5mm
• Special Features: DisplayPort Alternate Mode, USB Type C Female port supports power and data, 1x  Battery Charging 1.2 port

Connectors

• Inputs: 1 x USB Type C (Male)
• Outputs: 1x HDMI® (Female), 1x DisplayPort (Female), 1x RJ45 (Female), 2x USB Type A (Female), 1x USB Type C (Female) / 1x SD slot, 1x 3.5mm Audio (Female)
• Power: 1 x USB Type C (Female) PD port

Physical Properties

• Dimensions WxDxH: 116.5x61x16mm (4.59x2.4x0.63in)
• (Fixed) cable length: 250mm (9.84in)
• Housing Material: Aluminium
• Net Weight: 0.115kg (0.25lb)
• Operating Temperature: 0° - 55°C (32°F - 131°F)
• Storage Temperature: -10°C - 70°C (-14°F - 158°F)
• Humidity: 0 - 85% RH (non-condensing)
• Power Requirements: 15W
• Colour: Grey

Miscellaneous

• Packaging Type: Carton Box
• Packaging Dimensions: 150x137x120mm (5.91x5.39x0.79in)
• Gross Weight: 0.15kg (0.33lb)
• Warranty (Years): 2
• Certificated: CE, UKCA, FCC, REACH & RoHS, California Proposition 65

Package Contents

• USB 3.2 Type C Laptop Mini Dock
• Lindy Manual

Purchasing information

• No.: 43323
• EAN: 4002888433235
