150m USB 2.0 Cat.6 Extender

The Lindy 150m USB 2.0 Cat.6 Extender can be used to extend the distance between a USB peripheral device and host computer by up to 150m. It consists of a transmitter unit which connects to the computer and a receiver unit that connects to the device. Standard Cat.6 network cable (not included) is then used to bridge the connection between the two units. For best performance and compatibility, we recommend the use of solid core patched cables.

This USB 2.0 Extender is suitable for many long-distance applications like remote printing, camera surveillance or controlling machines.  This USB 2.0 Extender is supplied with a power adapter for the receiver unit to ensure secure and uninterrupted power. The robust metal housing makes it ideal for rugged environments.

Specifications

• USB Standard: USB2.0
• Supported Bandwidth: 480Mbps
• Maximum Distance: 150m (492ft)
• Transmission Medium: Cat. 6 UTP network cable
• Chipset: CH317Q
• Special Features: Supports isochronous data transfer, LEDs for Power, Link, Activity

Connectors

• Transmitter Input:  USB Type B (Female)
• Transmitter Output:  RJ45 (Female)
• Receiver Input:  RJ45 (Female)
• Receiver Output: USB Type A (Female)
• Power: 3.5/1.35mm DC socket

Physical Properties

• Dimensions WxDxH: 67x32x25mm (2.6x1.3x1.0in) / unit
• Housing Material: Metal
• Net Weight: 0.084kg (0.19lb) per unit
• Operating Temperature: 0° - 50°C (32°F - 122°F)
• Storage Temperature: -20°C - 70°C (-4°F - 158°F)
• Humidity: 10 - 90% RH (non-condensing)
• Power Requirements: 5V DC 3A
• Colour: Black

Miscellaneous

• Packaging Type: Carton Box
• Packaging Dimensions: 220x194x60mm (8.66x7.64x2.36in)
• Gross Weight: 0.6kg (1.32lb)
• Warranty (Years): 2
• Product Compliance: CE, FCC, RoHS & REACH, CP65

Package Contents

• Transmitter unit
• Receiver unit
• Multi-Country Power Supply (EU, UK, US & AUS)
• Lindy Manual

Purchasing Information

• No.: 43391
• EAN: 4002888433914
